Recoil RL680.4 - 4 Channel Class D 680 Watts 170W x 4 RMS Compact Car Amplifier
The Recoil L-3 series amplifiers are designed with one function in mind, performance. These amplifiers are a cost-effective solution for anyone needing to up their car audio game. Available in a 4-channel and mono version, L-3 will get you cranking it up without breaking the bank
Specifications
- 4-Way Protection Circuit: Thermal, Voltage, Speaker, DC
- Power @ 1 Ohm (14.4V): N/A
- Power @ 2 Ohm (14.4V): 170 Watts × 4
- Power @ 4 Ohm (14.4V): 95 Watts × 4
- Power (Bridged) @ 4 Ohm (14.4V): 250 Watts × 2
- Power (Bridged) @ 2 Ohm (14.4V): N/A
- Operating Voltage: 9V–16V
- Idling Current (Power On): 750mA
- Frequency Response: 20Hz–35kHz
- Signal-to-Noise Ratio (SNR): 89dB
- THD+N (@1W): 0.16%
- Input Sensitivity (Low Level): 220mV–12V
- Input Sensitivity (High Level): N/A
- Bass Boost: N/A
- Subsonic Filter: N/A
- Crossover LPF: 30Hz–300Hz
- Crossover HPF: 30Hz–300Hz
- Bass Remote: N/A
- Clip Indication: 1%
- Fuse Rating: 35A
Dimensions:
- Inches: 3.97" × 4.92" × 2"
- Metric: 108mm × 125mm × 51mm
