Kenwood KMM-205 Digital Media Receiver with Front USB & AUX Input. Digital Media Receiver Removable front panel with Red key illumination Android Music playback iPhone/iPod USB AUX 1 Preouts.
Key Features
- Short body media receiver
- 13 Digits vertical alignment LCD display.
- Red key & white display illumination.
- Dual Accent Key.
- FM (RDS) / AM (MW/LW) tuner (24presets).
- Illuminated front USB with dust cover (1,0A).
- MP3/WMA/WAV/FLAC playback.
- iPhone/iPod & Android music playback.
- 3-band EQ built-in.
- 1 RCA (rear/sub switchable) preout (2,5V).
General Features
- DIN Size 1 DIN
- Detachable Faceplate
- Key Illumination Red LED
- Rotary Encoder & Control Knob
- Dual Accent Key Audio control & Easy EQ control
- Back-up Memory Radio presets
- Attenuator with Smooth Volume Return
- Touch Sensor Tone
- Digital Clock (24H)
- Clock display when power-off default off
- All-off Select (20/40/60 minutes)
- Built-in Connector Mitsumi, 16 pin
- ISO connector Mitsumi to ISO cable
- USB interface x 1 (Front)
- Firmware upgreadable
- Mechless receiver
- Short body
Display Features
- Display Type Liquid Crystal Display (LCD)
- Display Layout 13 Segments x 13 Digit
- Vertical Aligment Liquid Crystal Display
- Display Illumination White (LED)
- Dimmer Control Manual / Set by Timer
- Brightness control 0 - 31 steps
- Demo Mode
- Menu text in selectable language English(default) / Spanish / French / Russian
Cosmetics Features
- Dress plate Piano Black
- Preset key finish Piano Black
- Escutcheon finish Black Injection
- Volume & operation knob or wheel Piano black with chrome finished ring
- Triangle Illumination Red LED
- Front terminals dust cover
- Key illumination Red LED
- Illuminated front USB port Red LED
- Brightness Control (Key) 0 - 31 step
- Dimmer Control (Key) Manual / Set by Timer
- Brightness zone concept 2 zone brightness control
Tuner Features
- Station Select Manual / Preset
- FM Reception
- AM (MW/LW) Reception
- Tuner Presets (FM/AM) 24 Presets (18FM / 6AM)
- Preset memory w/o back-up power
- Mixed preset memory (FM & AM) 6 presets
- Up/Down Seek/Scan
- Automatic Memory Entry (AME)
- FM Stereo / Mono Selector
- Radio Data System
- Radio Text Plus
- Traffic Information
- Local search
- AF Regional Selectable: AF/AF Reg/OFF
- Auto TP search
- Enhanced Other Networks Function (EON)
- Program Type Function (PTY)
USB Features
- USB terminal Front with dust cover
- USB Type 2.0 High speed
- Kenwood Music Control App for Android (with Android OS 4.1 ~ 7.0 )
- Android Open Accessory support (AOA) V 2.0
- MP3, WMA, WAV, FLAC playback
- Repeat/Scan/Random search
- Repeat / Random Play
- Direct search
- Resume play
- Time code display
- 1A Charge Capability for Smartphone
iPod Features
- Made for iPod & iPhone
- USB Direct Control (Audio, 1 wire, Lightning-connector) with optional cable KCA-iP103
- Music playback
- Alphabet search
- Skip search
- Related search
- Direct Search
- iPod EQ Mode
- Control by hand
- App & iPod control mode
- Spotify App Link
- iAP over Bluetooth
- iTunes Radio App iAP1
- Reverse browsing
Battery charge + power control
- *Always update to latest Apple firmware
Audio Features
- Maximum Output Power 50W x 4
- MOSFET Power IC
- Auxiliary Type Mini-jack, front panel
- Pre-out 1 RCA
- Pre-out Output Level 2.5V
- Preout Rear / Subwoofer Switchable
- Subwoofer Reference Level Adj
- Tone Control / Easy EQ 3-Band, 8 Presets
- Balance/Fader/Loudness Control Yes
- Bass Boost Circuit Off/+1/+2/+3/+4/+5
- Att.(-20dB) with smooth Volume Return
- Parametric Equalizer + Presets 3-Bands Parametric Equalizer with 8 Presets.
- Low-pass Filter
- Speaker Size Control Off / 5" or 4" / 6*9" or 6" / OEM
- Kenwood Sound Reconstruction
- Drive EQ
Connectivity
- Front USB & AUX Input
- OEM Wired Remote Control ready
- DC-Cord Mitsumi to ISO
- Power Control (P.CON) wire
- Amplifier pre-out 1 RCA: Rear/Subwoofer (selectable)
- FM Antenna Input JASO connector
