Kenwood CMOS 320 Universal Reversing Multi View Camera For AV Screens Rear
Universal Rear View Camera Reversing Camera Kenwood Screen
Key Features
- Universal Multi View Camera
- Night, Normal, Wide, Corner & Overhead View
- Switch Unit Included
- 1/3.6" Colour CMOS sensor
- Waterproof unit with flexible mount base
- NTSC Video Signal Out (RCA)
- Can be installed on the front or rear side of the car
Camera Unit
- Camera Type: 1/3.6" colour CMOS sensor
- Colour type
- Effective number of pixels roughly: 330000
- High sensitivity Pixels
- Output video: Wide-angle Mirror Image (for rearview)/Wide-Angle normal Image (for Front View
- Waterproof chassis
- Mounting system: Flexible mount base
- Installation positions: Rear
- Camera ID setting
- Rear view switching: Reverse line
- Front view switching: by remote or Kenwood unit
- Guideline Adjustments: Size, Horizontal Direction, Red Line Position
- Image Adjustments: Centering, Right-and-Left, Up-And-Down Angle
- High voltage protection
- Wide angle lens
- Focal length: f: 1.05mm, F value 2
- Horizontal Angle view: +/- 195 Degrees
- Vertical Angle View: +/- 145 Degrees
- Illumination range: approx. 0.9 to 100000 lux
- Iris System: Electronic
- White balance: Automatically
- Scanning System: Interlace
- Synchronizing System: Internal
- Video output level: 1Vpp, 75 Ohm
- Video signal format: NTSC (Mirror)
- Connection cable (DC+video): 5 m
