12TW1-2 12-inch (300 mm) Subwoofer Driver 2Ω Ohm
Built on JL Audio's patented thin-line subwoofer technology, the 12TW1 delivers a powerful combination of shallow mounting depth and excursion capability, while operating in insanely small enclosures (0.65 cu.ft. / 18.4 liters). This, combined with a special cast alloy frame design, makes the 12TW1 capable of operating in extremely tight spaces. These include under-seat installations in trucks, 2-seat sports cars and many other creative applications requiring a compact, low profile subwoofer design.
JL Audio's patented thin-line woofer technology compresses the architecture of the 12TW1 using a "concentric tube" structure built into the injection-molded cone body. This structure supports the voice coil and a full annular spider, while permitting the placement of a large motor structure further forward in the speaker than with conventional designs.
The 12TW1 also features a clever frame design that minimizes the frontal clearance required for the excursion of the driver. This is accomplished by recessing the suspension attachment surface, so that most of the forward excursion occurs within the frame's dimensions. Thanks to this feature, the 12TW1 requires only 0.87 inches (22 mm) of frontal clearance, even with its grille installed. This allows for more efficient use of space and increased enclosure volume within a given overall depth.
Key Specifics:
- Continuous Power Handling (RMS) 300 W
- Recommended Amplifier Power (RMS) 75 - 300 W
- Nominal Impedance (Znom) 2 Ω
- Nominal Diameter 12.0 in / 300 mm
- Overall Diameter (A) 12.375 in / 314 mm
- Mounting Hole Diameter (B) 11.0625 in / 281 mm
- Bolt Hole Circle Diameter (C) 11.7 in / 297 mm
- Motor Outer Diameter (D) 5.71 in / 145 mm
- Mounting Depth (E) 4.62 in / 117 mm
- Front Grille Protrusion (F) 0.87 in / 22 mm
- Driver Displacement 0.072 cu ft / 2.04 L
- Net Weight 16.5 lb / 7.5 kg
- Free Air Resonance (Fs) 35.06 Hz
- Electrical “Q” (Qes) 0.61
- Mechanical “Q” (Qms) 10.662
- Total Speaker “Q” (Qts) 0.577
- Equivalent Compliance (Vas) 1.008 cu ft / 28.54 L
- One-Way Linear Excursion (Xmax)* 0.40 in / 10.0 mm
- Efficiency (1 W / 1 m)** 85.07 dB SPL
- Effective Piston Area (Sd) 67.608 sq in / 0.0436 sq m
- DC Resistance (Re) 2.430 Ω
