Infinity Basslink Mini 200 Watts Compact Under Seat Powered Subwoofer System
Infinity BassLink MINI delivers deep bass and takes up little space. Infinity's smallest powered subwoofer can be hid in the most compact of locations and deliver exceptional performance to any car audio system. Powered by a 100Watts Amplifier, Basslink MINI delivers accurate, tight bass you would expect from Infinity, all while running cool and drawing minimal current from your vehicles charging system.
Features
Big Bass, Small Space
Infinity BassLink MINI delivers deep bass and takes up minimal space. Its on-board 100Wrms amplifier has been performance matched to subwoofer to deliver tight, accurate bass.
Intelligent Electronic Design for Reliable and Extraordinary Performance
The BassLink MINI employs high-pass filters and limiters that deliver exceptional at-the-limits performance.
Die-Casting Aluminum Enclosure Design
The all-die-cast aluminum enclosure design not only minimizes size but also eliminates rattles to deliver clear bass from tiny space.
Bass Volume Remote Control
Bass Volume Remote control is included to let you adjust the sound from the driver's seat.
Specifications:
- Driver Complement 6"x8"(152mmx203mm) Subwoofer
- Amplifier Power 100Wrms; 200W Max
- Frequency Response 30Hz – 150Hz
- Fuse 15A
- Maximum Current Draw 13 A
- Quiescent Current Draw <600 mA
- Input Sensitivity 0.1 V – 4.0 V Low-Level Input; 0.25 V – 20V High-Level Input
- Crossover Frequency 50 Hz – 150 Hz
- Crossover Slope 12 dB/octave
- Bass Boost 0dB to + 12dB @ 50Hz
- Dimensions (L x W x H) 11-7/16" x8-5/16" x 3" (289.6mm x 209.6mm x 75.0mm)
- Weight 8.22 lbs (3.73kg)
