GET READY FOR RAW POWER
Feed your system with the raw power from a MAX A2 amplifier! We welcome you to the next level with oversized capacitors and MOSFET transistors on a solid, double-sided PCB!
DUAL DIFFERENTIAL INPUT
The MAX A2 amplifiers are equipped with 2DP™, a state-of-the-art pre-amplifier with dual differential input circuits, because just like you we don’t like distortion. The 2DP™ will keep the unwanted noise at a minimum without compromising on the most important thing- awesome power.
HIGH QUALITY HIGH PASS
With great power comes the need for great precision crossovers. The MAX A2 have high quality 12dB high-pass filters and combined low- and band-pass filters, and to add even more control these CLASS AB amps come with a symmetrical push-pull power stage and AAB (Active Auto Bias)!
(And just to be sure, we have installed advanced safety systems including soft start and shutdown functions to protect your system against voltage spikes and drops, overload, overheating and short circuiting).
Specification:
- Component: Amplifier
- Product level: MAX A2
- Series: MAX
- Channels: Four
- Input mode: Mono / 2Ch, Mono / 2Ch / 4Ch
- Power RMS (2 Ohm): 4x230W
- Power RMS (4 Ohm): 4x150W
- Bridged Power RMS (4 Ohm): 2x460W
- Frequency response: 10-45,000 Hz
- Low Pass Filter: 30-4,000 Hz
- High Pass Filter: 10-4,000 Hz
- S/N Ratio (A-weighted): >102dB
- Bass EQ: 0-12dB @45Hz
- Crossover Slope: 12dB
- Power Voltage: 10-16V
- REM Voltage: 10-16V
- Input Sensitivity: 0.5-6V
- Input Impedance: 10K Ohm
- T.H.D: <0.05%
- Power Fuse: 3x35A
- Damping Factor: >150
- High Level Input: Yes
- RCA Line Out: Yes
