EDGE EDB80.4LITE-E2 Lite Series 4 Channel 640 Watts Car Amp Amplifier
The EDGE EDB80.4LITE-E2 is part of the DB Lite Series of amplifiers — a 4-channel, compact, high-value amplifier delivering up to 640 watts maximum power. It’s designed to power speakers or a combination of speakers and subwoofers, with active crossovers, bass-boost functions, and a robust Class AB topology for high-quality sound.
Key Features:
-
4-channel configuration — ideal for powering front/rear speakers or bridged to a subwoofer.
-
Active built-in crossovers (HP / LP / FLAT) for flexible system tuning.
-
Bass-boost circuit for enhanced low-frequency performance.
-
Extruded aluminium heatsink for improved cooling and compact installation.
-
Efficient Class AB design — optimum balance of efficiency and sound quality.
Specifications:
-
Channels: 4
-
RMS @ 4 Ω: 4 × 60 W / 2 × 160 W (bridged)
-
RMS @ 2 Ω: 4 × 80 W
-
Maximum Power: 640 W
-
Frequency Response: 20 Hz – 20 kHz
-
Crossover Range: 50 Hz - 4 kHz
-
Topology: Class AB
-
Dimensions (H × W × D): 58mm × 178mm × 323mm (2.3" × 7" × 12.7")
