JL Audio JX-500.1 JL Audio JX500/1 Class D Monoblock 500 Watt Car Amplifier
The JL Audio JX500.1 amplifier is a rugged and reliable Class D monoblock amplifier which uses a robust MOSFET power supply design that delivers rock-solid bass performance at a very affordable price.
Key Specifications:
- Class A/B Monoblock Subwoofer Amplifer
- 340 Watts RMS x 1 @ 4 ohm
- 420 Watts RMS x 1 @ 3 ohm
- 500 Watts RMS x 1 @ 2 ohm
- Frequency Response 10 Hz - 150 Hz (+0 -1dB)
- S/N Ratio referred to highest rated power - >90 dB below rated power (A-weighted 20 Hz - 20 kHz noise bandwidth)
- Min Copper Power / Ground Wire Gauge - 4AWG Cable
- Dimensions (LxWxH) 348mm x 195mm x 53mm
